| Frequency Response | 45–23,000 Hz ±3dB |
| Recommended Amplifier Power | 20—600 watts per channel |
| Horizontal Dispersion | 30° |
| Sensitivity | 90 dB/2.83 volts/meter |
| Impedance | 6 Ohms Compatible with 4, 6, or 8 Ohm rated amplifiers. |
| Crossover Frequency | 500, 2000 Hz |
| High Frequency Transducer | Two 1.25″ x 2.4″ (3.2cm x 6.1cm) Folded Motion XT Transducers with 4.5″ x 2.75″ (11.4cm x 7cm) diaphragm. |
| Mid Frequency Transducer | Patented CLS™ XStat™ electrostatic transducer. » Panel Dimensions: 8″ x 34.5″ (20.3 x 87.6cm) » Radiating Area: 276 in² (1,778 cm²) |
| Low Frequency Transducer | Four 6.5″ (16.5cm) cast basket, high excursion, rigid aluminum cone with extended throw drive assembly, non-resonance asymmetrical chamber format. |
| Amplifier | 1x 250 watts/channel (4 ohms), 500 watts peak |
| Room Correction (Bass Section) | Anthem Room Correction (ARC) Ready (Sold Separately) |
| Components | Custom-wound audio transformer, air core coils, polypro- pylene capacitors. 24-bit DSP based preamplifier (used with woofer amplifier). |
| Audio Controls | Bass: ±10dB under 75Hz Mid-Bass: –2dB, 0dB, +2dB ARC Room EQ: On, Off |
| Signal Inputs | WBT-0703Cu nextgen™ 5-way binding posts feature a filigree signal conductor made from gold plated, nickel free, non- ferromagnetic, pure copper for high conductivity and fully insulated. Free from eddy current effects. |
| Inputs | AC Power, RJ45 (for ARC), mini USB (for ARC) |
| Power Draw | Max: 300W per channel Standby: <1W per channel |
| Weight | 90 lbs. (40.9 kg) |
| Dimensions | 23.75″ x 32.35″ x 23.1 ” (60.3cm x 82.2cm x 58.6cm) |
