| Frequency Response | 68–22,000 Hz ±3dB |
| Recommended Amplifier Power | 20—300 watts per channel |
| Horizontal Dispersion | 30° |
| Vertical Dispersion | 28″ (71cm) line source |
| Sensitivity | 90 dB/2.83 volts/meter |
| Impedance | 6 Ohms, 1.3 @ 20kHz Compatible with 4, 6, or 8 Ohm rated amplifiers. |
| Crossover Frequency | 530Hz |
| High Frequency Transducer | XStat™ CLS™ electrostaic transducer » Panel Dimensions: 28″ x 8.6″ (71 x 22cm) » Radiating Area: 241 in² (1,562 cm² ) |
| Low Frequency Transducer | 6.5″ (16.5cm) high excursion, fiber cone with extended throw drive assembly; bass reflex |
| Components | Custom-wound E-I core transformer, air core coils, metal film capacitors |
| Inputs | Custom 5-way binding posts |
| Power Draw | Max: 2W each Standby: <1W each |
| Weight | 24.5 lbs. (11.1 kg) |
| Dimensions | 48.8″ x 9.4″ x 6.5 ” (123.9cm x 23.8cm x 16.5cm) |
