| Size & weight | |
|---|---|
| Dimensions |
Height: 160 mm (6.3 in) Cabinet only Width: 480 mm (18.9 in) Cabinet only Depth: 255 mm (10 in) Cabinet only 283 mm (11.2 in) including grille and terminals |
| Net Weight | 7.7 kg (17 lb) |
| Technical Details | |
|---|---|
| Technical Features |
Decoupled Double Dome Titanium tweeter Continuum™ cone bass / midrange Flowport™ |
| Description | 2-way vented-box system |
| Drive Units |
1x ø25mm (1 in) Titanium Dome high-frequency 2x ø130mm (5 in) Continuum cone bass / midrange |
| Frequency Range | -6dB 42Hz – 33kHz |
| Frequency Response | 72Hz – 28kHz ±3dB |
| Sensitivity | 87dB spl (on axis at 2.83Vrms at 1m) |
| Harmonic Distortion |
2nd and 3rd harmonics (90dB, 1m on axis) <1% 100Hz – 22kHz <0.5% 120Hz – 12kHz |
| Nominal Impedance | 8Ω (minimum 4.3Ω) |
| Recommended Amplifier Power | 30W – 120W into 8Ω on unclipped programme |
| Max Recommended Cable Impedance | 0.1Ω |
| Finishes | |
|---|---|
| Cabinet Finishes |
Black White Oak |
| Grille Finishes |
Black (Black) Grey (White and Oak) |
