| Features | |
|---|---|
| DAC Operation Mode: USB / Coax / Optical | Yes / No / No |
| Advanced AL 32 Plus | Yes |
| DAC Master Clock Design | ASRC in DAC |
| Customized Components | Yes |
| CD Compatibility: CD / CD-R/RW / WMA / MP3 / AAC | Yes / Yes / Yes / Yes / Yes |
| Others | |
|---|---|
| Separated Rectifier Circuit for Analog and Digital Circuitry | Yes |
| Display: Dimmer / Off | Yes / Yes |
| Playback | |
|---|---|
| Program Play (CD / SA-CD) | Yes / No |
| Repeat | Yes |
| Random Play | Yes |
| Inputs Outputs | |
|---|---|
| Headphone Out | No |
| Headphone Volume Control | No |
| Digital Optical In / Out | No / Yes |
| Digital Coaxial In / Out | No / Yes |
| Gold plated Cinch | Yes |
| Remote Control Bus in / out | Yes |
| Analogue Out (Cinch) | 2Ch |
| USB Audio (Front) / Made for iPod / Made for iPhone | Yes / No / No |
| USB-A File support | |
| MP3/WMA/AAC | Yes / Yes / Yes |
| WAV | Yes (~192kHz/24bit) |
| FLAC | Yes (~192kHz/24bit) |
| ALAC | Yes (~96kHz/24bit) |
| AIFF | Yes (~196kHz/24bit) |
| DSD (DIFF / DSF) | Yes (~5.6MHz) |
| Specifications | |
|---|---|
| Signal to Noise Ratio | 115 dB (CD/USB) |
| Frequency Response | USB (PCM/DSD): 2Hz – 50kHz (-3dB) CD: 2Hz – 20kHz |
| Total Harmonic Distortion | USB DSD: 0.0015% USB PCM 24bit: 0.0020% CD: 0.0025% |
| Line Level Output | 2.2Vms |
| D/A Conversion | DAC IC: ES9018K2M |
| Digital Filter | AL32 Processing Plus |
| Dynamic Range | 101 dB (CD) |
| General | |
|---|---|
| Metal Front Panel | Aluminum |
| Power Consumption in W | 24W |
| Standby Consumption in W | 0.3W |
| Remote Control | Yes |
| Auto Power Off | Yes |
| Weight | 4.9kg / 10.8lb |
| Available colors | Premium Silver / Black: Yes / Yes |
| Maximum Dimensions (W x D x H) | 434 x 328 x 107mm 17.1 x 12.9 x 4.2in |
| Carton Maximum Dimensions (W x D x H) | 524 x 476 x 197mm 20.6 x 18.8 x 7.8in |
| Carton Weight (inc. product) | 7kg / 15.4 lbs |
